The highly flexible load cables are applied at medium mechanical stress in the professional stage and lighting technology, and other load circuits. The flexibility is achieved through the building with extra fine 0,15 mm² strands and the core and sheath insulation from cold-flexible PVC.
| Cable structure | Conductor resistance Ohm/ km | Outer diameter app. mm | Cop. weight kg / km | Weight app. kg / km |
|---|---|---|---|---|
| 14 G 1.5 | < 13,3 | 13.4 | 201.6 | 322.0 |
| 18 G 1.5 | < 13,3 | 15.2 | 259.2 | 422.0 |
| 14 G 2.5 | < 7,98 | 16.6 | 336.0 | 487.0 |
| 18 G 2.5 | < 7,98 | 19.0 | 432.0 | 634.0 |
