DMX Power Combine Cable

KMCABLE DMX+POWER cable combines a shielded light control wire and the power supply wire. The DMX-cable, which is shielded by a copper braiding is perfectly suited for the control of light systems and mixing boards (110 Ohm characteristic intrinsic impedance). It highlights a soft PVC insulation and it is qualified for the use at indoor and outdoor installations. The DMX cable can also be used for the transmission of audio signals such as a microphone wire or as a power supply wire for active loudspeaker systems

Cable Structure:

(1x2x0,25)+3G1,5
Conductor: Bare copper
Insulation: PVC
Jacket: PVC
Insulation Color: Red White(DMX), Brown, Blue, Green/Yellow
Cable Overall Diameter: 13.2mm

Technical data:

Weight: app. 50 kg/km
Min. bending radius for laying: 64 mm
Operating temperature range min.: -30°C
Operating temperature range max.: +70°C
Copper weight: 60,5 kg/km

Electrical data

Characteristic impedance: 110 Ohm
Conductor resistance, max.: 78 Ohm/km
Insulation resistance, min.: 20 GOhm x km
